Minimal Fittings
CTBCS
Tee
ˇiSwivelˇj
Tube(Metric) - Thread(PT)
Style
D
R
F
P
L
H
CTB03M3C
3
M5x0.5
2
6
11.5
14.5
CTB03M5C
M5x0.8
16.5
CTB0301C
1/8
18.5
CTB04M3C
4
M3x0.5
3
8
14
14.5
CTB04M5CS
M5x0.8
16.5
CTB0401CS
1/8
18.5
CTB06M3C
6
M3x0.5
3
10
19
17
CTB06M5CS
M5x0.8
19
CTB0601CS
1/8
21
Tube(Inch) - Thread(NPT)
Style
D
R
F
P
L
H
CTB32M3C
3
M5x0.5
2
6
11.5
14.5
CTB321032C
10-32UNF
16.5
CTB3201CN
1/8
18.5
CTB04M3C
4
M3x0.5
3
8
14
14.5
CTB041032CS
10-32UNF
16.5
CTB0401CSN
1/8
18.5
CTB07M3C
6
M3x0.5
3
10
19
17
CTB071032CS
10-32UNF
19
CTB0701CSN
1/8
21
Tube(Metric) - Thread(G)
Style
D
R
F
P
L
H
CTB03M3C
3
M5x0.5
2
6
11.5
14.5
CTB03M5C
M5x0.8
16.5
CTB0301CG
1/8
18.5
CTB04M3C
4
M3x0.5
3
8
14
14.5
CTB04M5CS
M5x0.8
16.5
CTB0401CSG
1/8
18.5
CTB06M3C
6
M3x0.5
3
10
19
17
CTB06M5CS
M5x0.8
19
CTB0601CSG
1/8
21
