CTSCKN |
 |
 |
| ˇiSwivelˇj |
|
|
|
| Tube(
m / m ) - Thread( PT ) |
| Model |
 D |
R |
F |
F1 |
P |
L1 |
L2 |
H |
d |
| CTSCKN04M5 |
4 |
M5x0.8 |
10 |
8 |
12 |
20.6 |
22.9 |
34.7 |
4.3 |
| CTSCKN0401 |
1/8 |
| CTSCKN0402 |
1/4 |
14 |
| CTSCKN06M5 |
6 |
M5x0.8 |
12 |
10 |
14 |
22.4 |
25.6 |
38.1 |
| CTSCKN0601 |
1/8 |
| CTSCKN0602 |
1/4 |
14 |
| CTSCKN0603 |
3/8 |
17 |
| CTSCKN0801 |
8 |
1/8 |
14 |
12 |
16 |
24.1 |
29.1 |
46.5 |
| CTSCKN0802 |
1/4 |
| CTSCKN0803 |
3/8 |
17 |
| CTSCKN1002 |
10 |
1/4 |
14 |
21 |
29.1 |
34.6 |
48.8 |
| CTSCKN1003 |
3/8 |
| CTSCKN1004 |
1/2 |
21 |
| CTSCKN1202 |
12 |
1/4 |
19 |
17 |
35.5 |
49.8 |
| CTSCKN1203 |
3/8 |
| CTSCKN1204 |
1/2 |
21 |
|
| |
| Tube(
Inch ) - Thread( NPT ) |
| Model |
D |
R |
F |
F1 |
P |
L1 |
L2 |
H |
d |
| CTSCKN041032 |
5/32 |
10-32UNF |
10 |
8 |
12 |
20.6 |
22.9 |
22.5 |
4.3 |
| CTSCKN0401N |
1/8 |
34.7 |
| CTSCKN0402N |
1/4 |
14 |
| CTSCKN071032 |
1/4 |
10-32UNF |
12 |
10 |
14 |
22.4 |
25.6 |
24.5 |
| CTSCKN0701N |
1/8 |
38.1 |
| CTSCKN0702N |
1/4 |
14 |
| CTSCKN0703N |
3/8 |
17 |
| CTSCKN0801N |
5/16 |
1/8 |
14 |
12 |
16 |
24.1 |
29.1 |
46.5 |
| CTSCKN0802N |
1/4 |
| CTSCKN0803N |
3/8 |
17 |
| CTSCKN0902N |
3/8 |
1/4 |
14 |
21 |
29.1 |
34.6 |
48.8 |
| CTSCKN0903N |
3/8 |
| CTSCKN0904N |
1/2 |
21 |
| CTSCKN1302N |
1/2 |
1/4 |
19 |
17 |
35.5 |
49.8 |
| CTSCKN1303N |
3/8 |
| CTSCKN1304N |
1/2 |
21 |
|
| |
| Tube(
m / m ) - Thread(G) |
| Model |
D |
R |
F |
F1 |
P |
L1 |
L2 |
H |
d |
| CTSCKN04M5 |
4 |
M5x0.8 |
10 |
8 |
12 |
21.6 |
22.9 |
36.7 |
4.3 |
| CTSCKN0401G |
1/8 |
| CTSCKN0402G |
1/4 |
14 |
| CTSCKN06M5 |
6 |
M5x0.8 |
12 |
10 |
14 |
23.4 |
25.6 |
40.1 |
| CTSCKN0601G |
1/8 |
| CTSCKN0602G |
1/4 |
14 |
| CTSCKN0603G |
3/8 |
17 |
| CTSCKN0801G |
8 |
1/8 |
14 |
12 |
16 |
25.1 |
29.1 |
48.5 |
| CTSCKN0802G |
1/4 |
| CTSCKN0803G |
3/8 |
17 |
| CTSCKN1002G |
10 |
1/4 |
14 |
21 |
30.1 |
34.6 |
50.8 |
| CTSCKN1003G |
3/8 |
| CTSCKN1004G |
1/2 |
21 |
| CTSCKN1202G |
12 |
1/4 |
19 |
17 |
35.5 |
51.8 |
| CTSCKN1203G |
3/8 |
| CTSCKN1204G |
1/2 |
21 |
|
