| Tube(Metric)-Thread(PT) |
| Model |
 D |
Rc |
F |
L |
| CTCF0401 |
4 |
1/8 |
14 |
23.8 |
| CTCF0402 |
1/4 |
17 |
26.8 |
| CTCF0601 |
6 |
1/8 |
14 |
23.8 |
| CTCF0602 |
1/4 |
17 |
26.8 |
| CTCF0603 |
3/8 |
21 |
27.8 |
| CTCF0801 |
8 |
1/8 |
14 |
23.8 |
| CTCF0802 |
1/4 |
17 |
26.8 |
| CTCF0803 |
3/8 |
21 |
27.8 |
| CTCF1002 |
10 |
1/4 |
17 |
28.3 |
| CTCF1003 |
3/8 |
21 |
29.3 |
| CTCF1004 |
1/2 |
24 |
34 |
| CTCF1202 |
12 |
1/4 |
17 |
28.3 |
| CTCF1203 |
3/8 |
21 |
29.3 |
| CTCF1204 |
1/2 |
24 |
34 |
|
| Tube(Inch)-Thread(NPT) |
| Model |
D |
Rc |
F |
L |
| CTCF0401N |
5/32 |
1/8 |
14 |
23.8 |
| CTCF0402N |
1/4 |
17 |
26.8 |
| CTCF0701N |
1/4 |
1/8 |
14 |
23.8 |
| CTCF0702N |
1/4 |
17 |
26.8 |
| CTCF0703N |
3/8 |
21 |
27.8 |
| CTCF0801N |
5/16 |
1/8 |
14 |
23.8 |
| CTCF0802N |
1/4 |
17 |
26.8 |
| CTCF0803N |
3/8 |
21 |
27.8 |
| CTCF0902N |
3/8 |
1/4 |
17 |
28.3 |
| CTCF0903N |
3/8 |
21 |
29.3 |
| CTCF0904N |
1/2 |
24 |
34 |
| CTCF1302N |
1/2 |
1/4 |
17 |
28.3 |
| CTCF1303N |
3/8 |
21 |
29.3 |
| CTCF1304N |
1/2 |
24 |
34 |
|
| Tube(Metric)-Thread(G) |
| Model |
D |
Rc |
F |
L |
| CTCF0401G |
4 |
1/8 |
14 |
23.8 |
| CTCF0402G |
1/4 |
17 |
26.8 |
| CTCF0601G |
6 |
1/8 |
14 |
23.8 |
| CTCF0602G |
1/4 |
17 |
26.8 |
| CTCF0603G |
3/8 |
21 |
27.8 |
| CTCF0801G |
8 |
1/8 |
14 |
23.8 |
| CTCF0802G |
1/4 |
17 |
26.8 |
| CTCF0803G |
3/8 |
21 |
27.8 |
| CTCF1002G |
10 |
1/4 |
17 |
28.3 |
| CTCF1003G |
3/8 |
21 |
29.3 |
| CTCF1004G |
1/2 |
24 |
34 |
| CTCF1202G |
12 |
1/4 |
17 |
28.3 |
| CTCF1203G |
3/8 |
21 |
29.3 |
| CTCF1204G |
1/2 |
24 |
34 |
|
