Push In Fittings
Push In Type
Compress Type
CTV
Union Elbow
Ħi Swivel Ħj
Tube(Metric)
Model
D
P
L
H
CTV04
4
10
19
22.8
CTV06
6
12
19.5
CTV08
8
14
21
25.8
CTV10
10
16
24
29.3
CTV12
12
19
26.5
32.3
Tube(Inch)
Model
D
P
L
H
CTV04
5/32
10
19
22.8
CTV07
1/4
12
19.5
CTV08
5/16
14
21
25.8
CTV09
3/8
16
24
29.3
CTV13
1/2
19
26.5
32.3
CTVG
Different Dia. Union Elbow
Ħi Swivel Ħj
Tube(Metric)
Model
D1
D2
P1
P2
L
H
CTVG0604
6
4
12
10
19
22.8
CTVG0806
8
6
14
14
19.5
CTVG1006
10
16
21
25.8
CTVG1008
10
8
24
29.3
CTVG1210
12
12
19
19
26.5
32.3
Tube(Inch)
Model
D1
D2
P1
P2
L
H
CTVG0704
1/4
5/32
10
10
19
22.8
CTVG0807
5/16
1/4
14
14
19.5
CTVG0907
3/8
16
21
25.8
CTVG0908
3/8
5/16
24
29.3
CTVG1309
1/2
1/2
19
19
26.5
32.3
