CTXN |
 |
 |
| Ħi
Swivel Ħj |
|
|
|
| Tube(Metric)
- Thread(PT) |
| Model |
 D |
R |
F |
F1 |
P |
L |
H |
d |
| CTXN04M5 |
4 |
M5x0.8 |
10 |
10 |
12 |
25 |
56.8 |
3.3 |
| CTXN0401 |
1/8 |
57.8 |
| CTXN0402 |
1/4 |
14 |
| CTXN06M5 |
6 |
M5x0.8 |
10 |
12 |
58.7 |
| CTXN0601 |
1/8 |
| CTXN0602 |
1/4 |
12 |
| CTXN0603 |
3/8 |
17 |
| CTXN0801 |
8 |
1/8 |
14 |
14 |
14 |
29 |
63.8 |
4.3 |
| CTXN0802 |
1/4 |
| CTXN0803 |
3/8 |
17 |
| CTXN1002 |
10 |
1/4 |
17 |
16 |
33.5 |
69.3 |
| CTXN1003 |
3/8 |
| CTXN1004 |
1/2 |
21 |
|
| |
| Tube(Inch)
- Thread(NPT) |
| Model |
D |
R |
F |
F1 |
P |
L |
H |
d |
| CTXN041032 |
5/32 |
10-32UNF |
10 |
10 |
12 |
25 |
56.8 |
3.3 |
| CTXN0401N |
1/8 |
57.8 |
| CTXN0402N |
1/4 |
14 |
| CTXN071032 |
1/4 |
10-32UNF |
10 |
12 |
58.7 |
| CTXN0701N |
1/8 |
| CTXN0702N |
1/4 |
12 |
| CTXN0703N |
3/8 |
17 |
| CTXN0801N |
5/16 |
1/8 |
14 |
14 |
14 |
29 |
63.8 |
4.3 |
| CTXN0802N |
1/4 |
| CTXN0803N |
3/8 |
17 |
| CTXN0902N |
3/8 |
1/4 |
17 |
16 |
33.5 |
69.3 |
| CTXN0903N |
3/8 |
| CTXN0904N |
1/2 |
21 |
|
| |
| Tube(Metric)
- Thread(G) |
| Model |
D |
R |
F |
F1 |
P |
L |
H |
d |
| CTXN04M5 |
4 |
M5x0.8 |
10 |
10 |
12 |
25 |
56.8 |
3.3 |
| CTXN0401G |
1/8 |
57.8 |
| CTXN0402G |
1/4 |
14 |
| CTXN06M5 |
6 |
M5x0.8 |
10 |
12 |
58.7 |
| CTXN0601G |
1/8 |
| CTXN0602G |
1/4 |
12 |
| CTXN0603G |
3/8 |
17 |
| CTXN0801G |
8 |
1/8 |
14 |
14 |
14 |
29 |
63.8 |
4.3 |
| CTXN0802G |
1/4 |
| CTXN0803G |
3/8 |
17 |
| CTXN1002G |
10 |
1/4 |
17 |
16 |
33.5 |
69.3 |
| CTXN1003G |
3/8 |
| CTXN1004G |
1/2 |
21 |
|
